The Magnetic Field Coils Coupled According To The Provision of Helmholtz

Product Code:	DUFONLAB-LAB900455
Categories:	All Lab Equipments
Tags:	The Magnetic Field Coils Coupled According To The Provision of Helmholtz

Download PDF Enquire Now

The Magnetic Field Coils Coupled According To The Provision of Helmholtz Manufacturer in India

Specification

Principle:

A constant magnetic field, its magnitude and direction known, is superimposed on the unknown earth magnetic field.

The earth-magnetic field can then be calculated from the magnitude and direction of the resulting flux density.

Benefits:

Particularly homogeneous magnetic field and high flux density due to large Helmholtz coil diameter

Setup with precalibrated teslameter does not require additional magnets and coils for calibration

Tasks:

The magnetic flux of a pair of Helmholtz coils is to be determined and plotted graphically as a function of the coil current.

The Helmholtz system calibration factor is calculated from the slope of the line.

The horizontal component of the earth-magnetic field is determined through superimposition of the Helmholtz field.

The angle of inclination would be determined in order to calculate the vertical component of the earth-magnetic field.

DESCRIPTION :-

Earth's magnetic field

magnetic field of one coil pair in the Helmholtz configuration

Magnetic moment in a field magnetic

The set includes :-

Set of two Helmholtz coils

Universal Power DC: 0 ... 18 V, 0 ... 5 A / AC: 2/4/6/8/10/12/15 V, 5 A

Variable transformer with rectifier DC 12 V, 5 A / AC: 15 V, 5 A

Rheostat, 100 Ohm, 1.8A

Digital teslameter

Axial Hall probe

Digital multimeter manual

Compass inclination / declination

Set of circular conductors

Torsion dynamometer, 0.01 N

Spool

Distributor

A foot -PASS-

Support rod 18/8 stainless steel, 600 mm, Ø 10 mm

Socket

Bosshead -PASS-

Rod connector

Ruler, l = 1000 mm

Table clamp

Connecting cord, 750 mm, red

Connecting cord, 750 mm, blue
