Product Code: DUFONEP703513 - (Microprocessor K.F. Moisture Titrator)
Microprocessor K.F.
Moisture Titrator
Features:-
Auto Computation
of Moisture in ppm, %& mg H2O.
Storage of Date,
Time, Batch No. and Final Results
8-Digit Digital
Display
Motorized
Dispensing
External Printer
Attachment Facility
Microprocessor
KF Moisture Titrator is the finest volumetric titrator available.
It uses the
latest microcontroller technology and advanced engineering techniques so as to
give enhanced accuracy and reproducibility.
The system has
user friendly prompts which guide you throughout the titration process.
This titrator
eliminates the use of conventional delicate and fragile glass burettes and
plunger systems.
It uses a highly
sensitive motorized dispensing system for precise control of titrant volumes.
This titrator
analyses the moisture concentration of liquid samples, powder, fine particles
and fiber samples that are soluble in alcohol or solvents.
The moisture
content is displayed in ppm, %age and mg H2O.
The system has 24 soft touch membrane type keys for ease of operation.
Complete numeric
keypad is provided so as to feed the values of sample, density, titer factor,
date, time etc. comfortable.
The End Point
indication is given by both visual LED and audible alarm.
The titrator has
the facility for automatically calculating the titer factor of the Karl Fischer
reagent.
It uses the
repeated averaging method so as to give the most accurate titer value.
It has the
storage facility of date, time, batch no. and final results of 20 titrations
using the FIFO method.
The internal
battery backup ;provision has been made to store the results and the other
titration parameters for a minimum of 1 month even if the instrument is not
switched ON.
Provision for
external printer attachment is available so that any of the stored results can
be printed even at a later stage.
Specifications:-
Measuring
Range
10 ppm to 100%
of moisture
Measuring
Method
Karl Fischer
Volumetric Titration method.
K.F.
Dispensing
Highly
sensitive motorized dispensing system.
Resolution of
Titrant Volume
0.01 ml
Indication of
Titrant Volume
0.00 to 99.99
ml on display
Moisture
content calculation (Automatic)
%age : (0.00
to 100%)
ppm :: (1000010 to 9999999)
mg H2O : (0.00 to 999.99)
KF Titer
Factor
In-built
Automatic KF Titer Factor calculation facility
End Point
Alarm
Visual LED and
Audible Alarm
Dispensing
Pump Calibration
Available
through Key board
Wait Time for
End Point
Adjustable (100001
to 59 seconds)
Key Board
24 keys soft
touch membrane type
Sample storage
Up-to 20
latest samples using FIFO memory
Display
8 digit bright
red seven segment display.
Clock
In-built clock
with date & time display
Stirrer
In-built
Magnetic stirrer with adjustable speed.
Reagent Bottle
3x250ml bottle
for KF Reagent, methanol & calcium chloride
Printer
Interface
External
Serial printer interface available.
Power Supply
230V A.C ± 10%
50 Hz.
Dimensions
360 x 295 x
175 mm
Accessories
Dual Platinum
Electrode, Built-In Magnetic Stirrer, 250ml Bottle for Methanol, 10 Syringe,
Adapter for KF Reservoir, Set of Dispenser Tubes, Bottle Container, Dust
Cover, Titration Vessel with Teflon Cover, Teflon Coated Magnetic Stirring
Capsule, 250 ml Reservoir Bottle for KF Solution, 250 ml bottle for Calcium
Chloride, Adapter for Methanol Reservoir Bottle, Set of Connecting Tubes,
Main Lead, Instruction Manual....
