Spectrum Analyzer

Download PDF Enquire Now

Spectrum Analyzer Manufacturer in India

Specification

• Frequency range: 9 kHz to 3.5 GHz.

• Frequency resolution: 1 Hz

• Reference frequency: 10MHz

• Initial calibration accuracy: < 1 ppm

• Aging rate: 2 ppm/year

Frequency Readout Accuracy

• Marker resolution: span/ (number of

sweep paints - I)

Frequency Counter

• Resolution: I Hz, 10 Hz, 100 Hz, 1 kHz, 10 kHz, 100kHz

• Frequency Span Range: 0 Hz. 100 Hz to maximum frequency of instrument

• SSB Phase Noise: 20°C to 30°C, fc = I GHz

Maximum rated input level

• DC voltage: 50 V

• CW RF power: RF input-33 dBm ( 2 W)

• RF outout-23 dBm ( 0.2 W)

• Peak RF Power: RF input, duration < 3 s-36 dBm ( = 4 W)

• RF output, duration <3 s-26 dBm (- 0.4 W)

Trigger functions

• Trillller source: free run. video, external. IQ power (FPC-K7 ASK/FSK only)

• External trigger level threshold: low,high transition -2.4 V

• high-+ low transition-0.7 V.

• Maximum: 3V

• Warranty for 2 year.

• Operation manual would be provided.
