Force Table

Force Table For verifying the laws of triangle, parallelogram and polygon of forces, the force table is used.   This consists of machined aluminium table 40 cm in diameter.  Its raised rim has a scale, graduated in 360 degree, mounted on vertical support rod based provided with levelling screws.  Body under study is a ring in center of the table fastened by cords passing over four pulleys, attached with the table. Complete with four pulleys, four weight hangers, twelve weights  2 x 10 gm 2 x 20 gm 4 x 50 gm 4 x 100 gm
