Infinity Corrected Binocular Microscope

Infinity Corrected Binocular Microscope Description:- EDUCATIONLab microscope is versatile and suitable for use in clinics, research laboratories, or multi disciplinary. EDUCATIONLab microscope delivers quality results and features infinity corrected optics that enhance the image quality and allows the objectives to remain parfocal when optical components are added or removed. The rectangular shape and cast aluminum stand features minimum vibrations and provides a strong and stable operation.  The frame and handle make this microscope easy to be carried and moved in any work setting. Specification:- Viewing Head EDUCATIONLab binocular head which will not change the length in the eyepiece tubes when interpupillary distance adjustments are made 30° inclined and 360° rotatable Interpupillary adjustment of 50mm-75mm Eyepiece Wide field (WF)10x/20mm Diopter adjustable on left eyepiece tube Calibrated eyepiece pointer on one eyepiece Optional reticule eyepiece available for measurement purposes: 0.1mm Scales available (not included) Nosepiece Revolving reversed quadruple objective nosepiece accepts four objectives which are color-coded, parcentered and parfocaled. The nosepiece runs on ball bearings and has internal click stops so that the image remains centered after each change in magnification. Objectives Infinity corrected, E Plan Achromatic DIN 4X/0.10 ∞/0.17 Infinity corrected, E Plan Achromatic DIN 10X/0.25 ∞/0.17 Infinity corrected, E Plan Achromatic DIN 40XR/0.66 ∞/0.17 Infinity corrected, E Plan Achromatic DIN 100XR/1.25 oil ∞/0.17 40XR and 100XR objectives are retractable which have resilient mounts for specimen protection Focusing System Low position coaxial coarse and fine focus knobs on both sides Coarse movement stroke of 26mm Fine focus graduation of 2µm Focusing range 19mm Tension adjustment eliminates focus drift Stage 145mm x 140mm built-in double layer mechanical stage smooth X/Y calibrated movement with cross travel range 7.6cm x 5.2cm Two slides holder Illumination N.A. 1.25 Abbe condensers which height is controlled by a rack and pinion gear system that allows the condenser focus to be adjusted for proper illumination of the specimen Adjustable aperture  iris diaphragm incorporated into the condenser, which is important in securing correct illumination, contrast, and depth of field;  a graduated scale indicates the approximate adjustment (size) of the aperture diaphragm corresponding to respective objectives. 3W LED with light intensity control provide cool, bright, and even illumination Other Characters Original integrated stand, rectangular shape and cast aluminium frame for minimum vibrations, maximum stability and  durability Carrying handle integrated in the back of the stand for easy carrying Arm and base made of one piece construction Antifungal treatment prevents fungal growth Optional Accessory Available (not included) Dark field kit (Dark field condenser N.A. 0.9 (Dry) for 4x-40x objective) Polarizing kit (Analyzer/Polarizer)
